High frequency inverter,running speed of the load is faster,quieter,stable waveform,more suitable for sensitive electrical or electronic products.
When the battery power is exhausted,the inverter can automatically activate the battery and charge,without manual start.
Item NO. :
Solar inverter GD series B 8-11KCertificate :
CE,ISO,ICE,SASO,SONCAP,UL,ROHS,UPS-CELead time :
30 daysMOQ :
≥1Payment :
T/TWarranty :
1 yearsApplicable Scenarios :
island/construction/housing/factory/meeting center/agriculture/animal husbandry48VDC 11KW Off Grid Hybrid Solar Inverter Support Lithium Battery Communication
The GD Series Solar Inverter Parallel Version is a high-performance and flexible inverter solution designed to meet the needs of modern solar energy systems. Available in power 11000W, this inverter supports parallel operation, allowing for seamless scaling and enhanced system reliability. Whether you're building a residential, commercial, or industrial solar power system, the GD Series offers the ideal combination of efficiency, flexibility, and durability.
Features:
1.Lithium Battery Auto-restart Function,More Convenient for lithium Battery Charging
2.Intelligent Power Supply Mode,Intelligent Distribution of solar Panel/Mains/Battery Power Shares
3.Utility Charging voltage/PV Charging Voltage Adjustable,Match Different Battery charging Requirements
4.Convenient Installation And Transportation
5.Battery Reverse Connection Protection with Fuse switch,Safer Installation
6.PF1.0,High Efficiency,Lower Consumption,Energy Conservation/environmental Protection/Electricity Saving/cost saving
7.Support Working without Battery:Reduce Solar system Cost
8.Parallel Function Up to Maximum 9 Units:Enlarge More Loads
9.BMS function for lithium battery
10.Communication Option:External WIFI,Supervise at Any Time
| Model | GD11048MHB | ||||
| Input voltage | Input Formation | L+N+PE | |||
| AC Input | 220/230/240VAC | ||||
| Input Voltage Range | 90-280VAC±3V(Normal Mode)170-280VAC±3V(UPS Mode) | ||||
| Frequency | 50/60Hz(Adaptive) | ||||
| Output | Rated Power | 11000W | |||
| Output Voltage | 220/230/240VAC±5% | ||||
| Output Frequency | 50/60Hz±0.1% | ||||
| Output Wave | Pure Sine Wave | ||||
| Transfer Time(Adjustable) | 10ms for Computer Equipment,20ms for Household Equipment | ||||
| Peak Power | 22000w | ||||
| Overload Ability | Battery Mode:21s@105%~150%Load 11s@150%~200%Load 400ms@>200%Load |
||||
| Grid connected Operation |
Output Voltage | 220/230/240VAC | |||
| Grid Voltage Range | 195-253VA | ||||
| Grid Frequency Range | 49-51±1Hz/59-61±1Hz | ||||
| Output Current | 47.8A | ||||
| Power Factor Range | >0.99 | ||||
| (DC/AC)Conversion Efficiency | 98% | ||||
| Battery | Rated Voltage | 48VDC | |||
| Constant Charging Voltage(Adjustable) | 56.4VDC | ||||
| Float Charging Voltage(Adjustable) | 54VDC | ||||
| Charger | PV Charging Method | MPPT*2 | |||
| Max PV Input | 2x5500W | ||||
| MPPT Tracking Range | 90~500VDC | ||||
| Best VMP Working Range | 300~400VDC | ||||
| MAX PV Input Voltage | 500VDC | ||||
| MAX PV Input Current | 18A/18A | ||||
| MAX PV Charge Current | 150A | ||||
| MAX AC Charge Current | 150A | ||||
| MAX Charge Current | 150A | ||||
| Display | LCD | Can display operating mode/load/input/output | |||
| Interface | RS232 | 5PIN/Pitch2.54mm,Baud Rate 2400 | |||
| Expansion Slot Communication Interface | Lthium Battery BMS Communication Card,WIFI 2×5PIN/Pitch2.54mm | ||||
| Parallel Interface | Support Parallel | ||||
| Ambient Temperature | Operating Temperature | -10℃~50℃ | |||
| Storage Temperature | -15℃~60℃ | ||||
| Ork Altitude | No more than 1000m,If 1000m<,Rate power will lower,MAX 4000m,Refer to IEC62040 | ||||
| Operating Environment Humidity | 20%~95%Non Condensing | ||||
| Noise | ≤50db | ||||
| Dimension | L*W*H(mm) | 570*500*148mm | |||
| Standards and Certifications | EN-IEC 60335-1,EN-IEC 60335-2-29,IEC 62109-1 | ||||
Application
